품명 : Aero 40 / AERO40
SPEC : MIL-H-5606 / BMS 3-32 Type II / MIL-PRF-6083 / MIL-PRF-5606/ Douglas DPM 6176
캐스트롤(Castrol)은 세계적인 윤활유 전문 회사입니다.
1899년에 처음 설립되어 현재는 BP 산하에 있는 캐스트롤 Castrol 은 지구 상의 모든 운전자, 모든 오토바이 라이더 및 모든 사업에 서비스를 제공하고 있습니다. 모든 용도에 적합한 고성능 오일, 윤활유, 유액 및 그리스를 만드는 윤활유 세계적인 회사입니다.
IT'S MORE THAN JUST OIL. IT'S LIQUID ENGINEERING
- 적용범위 : 항공기 landing gear shock struts 용 특수 유압유
- 제품개요 :
Castrol Aero 40은 MIL-H-5606 요건 충족 및 Douglas DPM 6176 사양을 충족하는 고품질 미네랄 기반 유압 오일로써 전단 안정성이 높은 점도 지수 향상제, 산화 방지제, 마모 방지제 및 랜딩 기어 외부 실린더의 마르텐 사이트 줄무늬 및 충격 스트럿 상부 베어링의 마모를 줄이는 승인 된 극압 첨가제를 포함합니다.
보잉 Boeing Spec BMS 3-32, Type II 을 만족하며 MIL 스펙 MIL-PRF-6083 사양 인증 유압유를 충족하는 승인 된 오일입니다. 다른 석유 기반 및 합성 탄화수소 윤활유와 호환되지만이 제품의 성능을 유지하려면 오염을 피해야합니다.
또한, Aero 40은 Boeing Service Letters 707-SL-12-2의 대안으로 공식화되었습니다. 727-SL-12-2; 737-SL-12-2; 및 757-SL-27-15-B
- 일반가격 및 대량문의 : 3XX,XXX원/5gal PAIL (전화문의 및 상담)
 |
|||
| Landing Gear Shock Strut Fluid | |||
| Description | |||
| Castrol AeroTM 40 is a high quality, mineral based MIL-H-5606 hydraulic fluid containing a highly shear stable viscosity index improver, an anti-oxidant, anti-wear agents, and an approved EP additive which reduce martensitic streaking of landing gear outer cylinders and galling of shock strut upper bearings. Aero 40 is available in either dyed red (Douglas Aircraft) or undyed, straw colored (Boeing Spec BMS 3-32, Type II). | |||
| Application | |||
| Aero 40 is designed for use in landing gear shock struts. It is compatible with approved MIL-PRF-6083 and other MIL-H- 5606 qualified hydraulic fluids. It is not completely compatible with synthetic gas turbine lubricants nor with phosphate-ester hydraulic fluids. It is compatible with other petroleum-based and synthesized hydrocarbon lubricants but contamination should be avoided in order to maintain the unique properties of Aero 40. This product is compatible with seals, hoses and paints normally used in shock struts and dispensing equipment connected with this application. While certain grades of the above materials are fully compatible with Aero 40, it is advisable to confirm acceptability of use with either the material manufacturer or Castrol. | |||
| Specification | |||
| Aero 40 -Red is formulated in accordance with Douglas Aircraft Specification DPS 3.334, referenced as douglas stock number DPM 6176. Additionally, Aero 40 is formulated as an alternative to Boeing Service Letters 707-SL-12-2; 727-SL-12- 2; 737-SL-12-2; and 757-SL-27-15-B, which instruct the addition of an EP additive to either the standard or corrosion inhibited mineral based hydraulic fluid for use in their landing gear shock struts. | |||
| Typical Characteristics | |||
| TEST (ASTM) | DESCRIPTION | RESULT | |
| D 287 | API Gravity @ 15.6/15.6°C (60/60°F) | 29.2 | |
| Pounds per Gallon @ 16ºC (60ºF) | 7.332 | ||
| D 445 | Kinematic Viscosity, cSt | ||
| @ 100ºC (212ºF) | 4.71 | ||
| @ 40ºC (104ºF) | 13 | ||
| @ -40ºC (-40ºF) | 510 | ||
| @ -54ºC (-65ºF) | 2670 | ||
| D 2270 | Viscosity Index | 344 | |
| D 92 | Flash Point, COC, ºC (ºF) | 108 (225) | |
| Fire Point, COC, ºC (ºF) | 116 (240) | ||
| D 97 | Pour Point, ºC (ºF) | -57 (-70) | |
| D 130 | Copper Strip Corrosion, 72 hrs @ 121ºC (250ºF) |
1a | |
| D 4172 | Four-Ball Wear-Test, AWSD, mm 1 hr @ 1200 rpm, 40 hgf 75ºC (167ºF) |
0.43 | |
| D 3233 | Falex Wear Characteristics, 500 lbf, Reference Load |
Pass | |
| Subject to usual manufacturing tolerances. | |||
| Castrol Aero 40 8/14/2008, version 7.0 Castrol, Aero and the Castrol logo are trademarks of Castrol Limited, used under licence. All reasonable care has been taken to ensure that the information contained in this publication is accurate as of the date of printing. However, such information may, nevertheless, be affected by changes in the blend formulation occurring subsequent to the date of printing. Material Safety Data Sheets are available for all Castrol Ltd products. The MSDS must be consulted for appropriate information regarding storage, safe handling and disposal of a product. Castrol Industrial North America Inc. 150 West Warrenville Road, 605 3E Naperville, IL 60563 Tel: (877) 641 1600 Fax: (877) 648 9801 www.castrol.com/industrial |
|||
